Quad Segway SNARLER AT6 S Standard

Quad Segway SNARLER AT6 S (Short Version) Standard

3 years WARRANTY

SNARLER AT6 S STANDARD - 570cc COMBUSTION ENGINE
Short version

SMART MOVING Smartphone App
Orange injected bodywork
Front differential with lock
4 independent wheels
Front bumper, tow ball
Front and rear luggage racks

570CC liquid-cooled thermal engine,

4 stroke, 4 valves,
Single cylinder,
Double overhead camshaft.
Bosch injection.
MAX44 CV
TORQUE 48 Nm

VERY HIGH STRENGTH CHROMIUM-MOLYBDENUM STEEL CHASSIS.

AIR SHOCK ABSORBERS - DOUBLE WISHBONE FRONT SUSPENSION
The SnarlerTM is equipped with adjustable front and rear shock absorbers that adapt to any type of terrain and any riding style.

The front suspension is a double wishbone suspension with a travel of 180mm, the rear suspension has a travel of 210mm.
With a ground clearance of 270mm, the SnarlerTM easily clears all obstacles and provides you with unparalleled driving pleasure with absolute comfort.

AUTOMATIC DIFFERENTIAL - 4X2/4X4 CONTROL AUTOMATIC DIFFERENTIAL, FRONT DIFFERENTIAL LOCK
4x2 / 4x4 front differential with automatic locking plus switchable rear differential lock.

From trails to mud to rocks, the SnarlerTM provides all the traction you need to conquer any type of terrain.

ENGINE / TRANSMISSION
Energy: Thermal
Engine type: 4-stroke single cylinder, double overhead camshaft
Cylinder capacity: 570 cc
Injection: Bosch
Power: 44 hp
Torque: 48 Nm
Transmission: 4x4 on demand
Front axle: Differential with lock
Engine brake: Yes

SUSPENSION
Front: 2 independent shock absorbers, 18 cm stroke
Rear: 2 independent shock absorbers, 21 cm stroke

WHEELS
Rims: Steel
Tires: Front: 25x8-12 - Rear: 25x10-12

OTHER EQUIPMENT
Frame: High-strength chromium-molybdenum steel
Cooling: Water cooling with liquid/oil exchanger

DIMENSIONS
Dimensions: 2150 x 1250 x 1540 mm
Ground clearance: 260 mm
Seat height: 930 mm
Wheelbase: 1300 mm
Dry weight: 359 kg
Tank: 23 l
Luggage rack capacity: Front: 40 - Rear: 80 kg

SMART INTERFACE
Smart control: Yes
Dashboard: Digital
Application: Yes
