Quad Masai A 550 ix

The Masai 550 IX is the useful and versatile adventurer in the range.
We appreciate it thanks to the approval of its single-cylinder engine powered by Delphi injection, as well as all the functions that allow it to go absolutely anywhere: 4x4 on demand, front and rear differential lock.

Likewise, its solid front and rear racks give it great versatility of use, whether for farm work or hiking.

ENGINE
Type: Single cylinder 4T
Displacement: 550cc
Bore x Stroke: 91 x 84mm
Compression: 9.4:1
Ignition: CDI
Cooling: Liquid
Starting: Electric / manual launcher

DIMENSIONS
Ground clearance: 295mm
Front tyres: 25/08/12
Rear tyres: 25/10/12
Dry weight: 334 kg
Traction on public roads: 162 kg
Tank: 15 liters
Fuel: Unleaded gasoline

FRAME
Transmission: Auto variator Long speed
or short + M. AR
+ 4x4 mode on demand
+ front and rear differential with lock
Final drive: By universal joint
Front suspension: 2 independent shock absorbers
Rear suspension: 2 independent shock absorbers
Front braking: Hydraulic 2 discs
Rear braking: Hydraulic 1 disc

EQUIPMENT:
Front and rear luggage racks
Winch
Hitch ball + hitch socket
12 inch aluminum rims
