ATV winch with nylon strap

Adaptable directly on Hytrack, Linhai, Masai, Dinli quads and on the majority of quads (if necessary adapter plate available as an option)

List of pieces :
Motor, wing wheels, seal, gear housing, toothed bell, nylon gear, planetary gear, gear, shaft, winch release, housing cover, M4x10 screw, brake spring, spacer shaft, drum, cable lock, wheel to release the winch, M5x28 hex screw, M6x16 assembly screw, ring, winch support, control box, strap, hook, pin and pin, cable clamp, cable, roller guide, wireless remote control.

Specifications:

- Traction: 1360 kg

- Much lighter than a steel cable winch, 1.5 kg less

- Long life in difficult use (water, sand, mud, salt)

- Motor: 12V DC 1.5 hp Permanent magnet motor, sealed

- Control box: waterproof

- Controls: Remote control (on the handlebars) or wireless remote control

- Gear pinion: 3-phase planetary

- Speed ratio: 153:1

- Clutch: slipper

- Clutch diameter and length: 38/73

- Cable strand: galvanized steel 4.8mm x13m

- Recommended battery: 12 Amp/hour minimum

- Guide: Roller

- Cycle: Intermittent

- Mounting screw arrangement (mm): 80 x 130

- Winch dimensions (mm): 315 x 105 x 105

- Weight: 10 kg

Performances of the 1360kg winch:

Drawing capacity per layer:
